Ġewż tat-twaħħil tal-Ġewż tal-Kap ORFS
Forma: Kap
Thread 1 Tip: Female O-Ring Face Siġill
Konformità: SAE 520112
O-Ring Face Siġill Adapters
Numru tal-Parti:
FS0304-Ċ
Attributi:
Forma: Kap
Thread 1 Tip: Female O-Ring Face Siġill
Konformità: SAE 520112
Daħħal tal-Assemblea tal-Kap tas-Siġill tal-wiċċ & Ġewż
Fittings ORFS (O-Ring Face Seal) għandhom ħajt dritta u wiċċ ċatt b'kanal O-ring maħdum fil-wiċċ ċatt. Is-siġillar isir billi tikkompressa l-O-ring fuq il-wiċċ ċatt tal-konnettur femminili.
PARTI NO. DAQS | TUBU OD | H O.D. | K LGTH |
FS0304-C-04 | 1/4 | 0.502 | 0.34 |
FS0304-C-06 | 3/8 | 0.620 | 0.37 |
FS0304-C-08 | 1/2 | 0.745 | 0.47 |
FS0304-C-10 | 5/8 | 0.923 | 0.47 |
FS0304-C-12 | 3/4 | 1.097 | 0.53 |
FS0304-C-16 | 1 | 1.347 | 0.59 |
FS0304-C-20 | 1-1/4 | 1.597 | 0.59 |
FS0304-C-24 | 1-1/2 | 1.910 | 0.59 |
It-tags Popolari: ORFS Cap Nut Fitting Nut, Ċina, manifatturi, bl-ingrossa, fl-istokk, magħmula fiċ-Ċina
